The Hikvision DS-2TD2617B-6/PA Temperature Screening Thermographic Bullet Camera is designed to enhance public safety by providing efficient and reliable temperature screening. This advanced device combines high-resolution thermal imaging with intelligent temperature measurement technology, ensuring fast and accurate detection of abnormal temperatures in various environments.
Quick Spec
| Brand | Hikvision |
| Model | DS-2TD2617B-6/PA |
| Image Sensor | Uncooled Focal Plane Arrays |
| Resolution | 160 120 |
| Temperature Range | 30C C 45C |
Product Features
- Enhanced thermal sensitivity for precise temperature detection.
- Dual-lens design for combining thermal and optical images.
- Advanced image processing technology for clearer visuals.
- Real-time alarm notifications for abnormal temperature readings.
- Flexible installation options for various environments.
Product Applications
- Entry points of airports and train stations for traveler safety.
- Public spaces like shopping malls and schools to manage large crowds.
- Healthcare facilities to monitor patient and staff temperatures effectively.
Supported Options
| Wall Mount | DS-1273ZJ-135 |
| Tripod | DS-2907ZJ |
| Monitor | DS-D5022QE |
Compare to Similar Items
| Model | Key Differences |
| DS-2TD1217B-3/PA | Lower resolution (120 90), shorter range |
| DS-2TD2636B-10/P | Higher resolution (384 288), longer range |
| DS-2TD2166T-25 | Higher sensitivity, advanced analytics |
Get more information
Check Hikvision DS-2TD2617B-6/PA price and DS-2TD2617B-6/PA datasheet, buy Hikvision DS-2TD2617B-6/PA with best price and fast shipping. Free Live Chat are supported. For further information about the product and its price, please contact us via Live Chat or at sales@router-switch.com.
Hikvision DS-2TD2617B-6/PA Specification
DS-2TD2617B-6/PA Specifications |
|
| Brand | Hikvision |
| Model | DS-2TD2617B-6/PA |
| Product Type | Temperature Screening Thermographic Bullet Camera |
| Sensor Resolution | 160 �� 120 |
| Thermal Sensitivity | ��40 mK |
| Temperature Measurement Range | 30��C to 45��C (86��F to 113��F) |
| Temperature Measurement Accuracy | ��0.5��C (��0.9��F) |
| Lens (Thermal) | 6 mm/2.4 inches |
| Field of View (Thermal) | 25�� �� 18.7�� |
| Image Sensor (Visible Light) | 1/2.7″ Progressive Scan CMOS |
| Effective Pixels (Visible Light) | 2688 �� 1520 |
| Lens (Visible Light) | 4 mm/0.16 inches |
| Field of View (Visible Light) | 84.5�� �� 44.2�� |
| Min. Illumination (Visible Light) | 0.0089 Lux @ (F1.6, AGC ON) |
| Networking Interface | RJ-45 Ethernet 10/100 Base-T |
| Video Compression Standards | H.265/H.264/MJPEG |
| Power Supply | 12 VDC �� 20%, PoE (802.3af) |
| Power Consumption | Max. 11 W |
| Operating Conditions | -20��C to 50��C (-4��F to 122��F) |
| Ingress Protection | IP66 |
