The D-Link DGS-1026TP-CN is a high-performance unmanaged PoE switch tailored to facilitate network management with its 24 Gigabit PoE electrical ports and 2 Gigabit optical ports. Designed to deliver a backplane bandwidth of 52G and a packet forwarding rate of 38.7M, it provides robust network speeds and efficiency. With a max power output of 370W, built-in power supply, and a compact iron case, it is ideal for rack mounting and offers ease of installation and durability.
Quick Spec
| Model | DGS-1026TP-CN |
| Ports | 24 Gigabit PoE + 2 Gigabit Optical |
| Backplane Bandwidth | 52G |
| Packet Forwarding Rate | 38.7M |
| Max Power per Port | 30W |
| Max Power Output | 370W |
| Dimensions | 440x208x44 mm |
Product Features
- 24 Gigabit PoE electrical ports plus 2 additional Gigabit optical ports
- High backplane bandwidth of 52G ensuring smooth data transmission
- Supports PoE with maximum power delivery of 30W per port
- Robust packet forwarding rate of 38.7M for efficient handling of network traffic
- Built-in power supply within a durable iron case suitable for rack mounting
Product Applications
- Small to medium-sized enterprise networks requiring high-speed data transfer and PoE support
- Video surveillance systems needing reliable power and data connection for multiple IP cameras
- Education institutions aiming to deploy efficient network setups in classrooms, laboratories, and administration offices
Supported Options
| Power Cable | MODEL-123 |
| Rack Mount Kit | MODEL-RMK456 |
| Optical Transceiver | MODEL-OT789 |
Compare to Similar Items
| Model | DGS-1026TP-CN | DGS-1210-24P | DGS-1100-24 |
| Ports | 24 Gigabit PoE + 2 Gigabit Optical | 24 Gigabit PoE | 24 Gigabit |
| Backplane Bandwidth | 52G | 56G | 48G |
| Packet Forwarding Rate | 38.7M | 41.67M | 35.7M |
| Max Power Output | 370W | 193W | N/A |
| Management Type | Unmanaged | Smart Managed | Unmanaged |
Get more information
For further information about the D-Link DGS-1026TP-CN and its pricing, please contact us through Live Chat or email us at sales@router-switch.com.
D-Link DGS-1026TP-CN Specification
DGS-1026TP-CN Specifications |
|
| Brand | D-Link |
| Model | DGS-1026TP-CN |
| Port Configuration | 24 Gigabit PoE electrical ports + 2 Gigabit optical ports |
| Backplane Bandwidth | 52 Gbps |
| Packet Forwarding Rate | 38.7 Mpps |
| Single Port Maximum Power | 30 W |
| Machine Maximum Power | 370 W |
| Power Supply | Built-in |
| Dimensions | 440 x 208 x 44 mm |
| Material | Iron case |
| Form Factor | Rack |
| Type | Unmanaged PoE Switch |
| Number of PoE Ports | 24 |
| Number of SFP Ports | 2 |
| Port Speed | 10/100/1000 Mbps |
| Network Standards | IEEE 802.3af, IEEE 802.3at |
| Operating Temperature | 0��C to 40��C (32��F to 104��F) |
| Storage Temperature | -10��C to 70��C (14��F to 158��F) |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 5% to 95% non-condensing |
| Power Input | AC 100-240V, 50/60Hz |
