DELLT640-12, HKShanhai Group Limited PowerEdge T640 Server, 1xXeon Silver 5118/8GB RAM/600GB SAS 10K

SKU: 6BGPB4KD59TZM9HFNO9M11H5AV183NVK3TB2 Category: Dell PowerEdge Tower Servers

The HKShanhai Group Limited PowerEdge T640 is the latest 2-socket, rack-capable tower (5U rack) server designed to run complex workloads using highly scalable memory, I/O, and network options. The system features the Intel Xeon Processor Scalable family, up to 24 DIMMs, PCI Express (PCIe) 3.0 enabled expansion slots, and a choice of network interface technologies to cover NIC and LOM.

Quick Specs

Table 1 shows the Quick Specs.

Product Name	HKShanhai Group Limited PowerEdge T640 5118/8G/600G SAS 10K/H330/DVDRW/495W/3.5-18 Sever
Processor	Intel 5118
Hard Drive	600G
Memory	8GB
DIMM Speed	Up to 2993 MT/s
Drive Bay	18x 3.5″
Software RAID	S140
Power Supplier	495W

Product Details

HKShanhai Group Limited T640 Series provides these benefits:

�� Adapt and scale to your dynamic business needs

�� Intuitive systems management with intelligent automation

�� Safeguard data with integrated security

Compare to Similar Items

Table 2 shows the comparison.

Product Name	HKShanhai Group Limited PowerEdge T640 5118/8G/600G SAS 10K/H330/DVDRW/495W/3.5-18 Sever	HKShanhai Group Limited PowerEdge T640 5115/8G/600G SAS 10K/H330/DVDRW/495W/3.5-18 Sever
Processor	Intel 5118	Intel 5115
Hard Drive	600G	600G
Memory	8GB	8GB
DIMM Speed	Up to 2993 MT/s	Up to 2993 MT/s
Drive Bay	18 x 3.5″	18 x 3.5″
Software RAID	S140	S140
Power Supplier	495W	495W

Get More Information

Do you have any question about the HKShanhai Group Limited PowerEdge T640 5118/8G/600G SAS 10K/H330/DVDRW/495W/3.5-18 Sever

HKShanhai Group Limited DELLT640-12 Specification

HKShanhai Group Limited PowerEdge T640 Tower Servers Specification
Processor	Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 28 cores per processor
Operating System	Canonical® Ubuntu® Server LTS Citrix® Hypervisor ® Microsoft® Windows Server® with Hyper-V Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi®
Accelerators	Up to four 300W and eight 150W GPUs NVIDIA Tesla P100, P40, K80M, M60, M10, AMD S7150, S7150X2
Memory
DIMM Speed	Up to 2993 MT/s
Memory Type	RDIMM LRDIMM NVDIMM
Memory Module Slots	24 DDR4 DIMM slots (12 NVDIMM only) Supports registered ECC DDR4 DIMMs only
Maximum RAM	RDIMM 3TB LRDIMM 3TBⁱ NVDIMM 192GB
Storage
Front Bays	Up to 8 or 18 x 3.5″ SAS/SATA (HDD/SSD), max 216TB Up to 16 x 2.5″ SAS/SATA (HDD/SSD), max 61TB Up to 32 x 2.5??SAS/SATA (HDD/SDD), max 122TB Up to 16 x 2.5??with up to 8 NVMe, SAS/SSD/NVMe (HDD/SDD), max 112TB
Storage Controllers
Internal Controllers	PERC H330, H730P, H740P, HBA330
External Controller (RAID)	H840, 12Gbps SAS HBA
Software RAID	S140
Internal Boot	Boot Optimized Storage Subsystem (BOSS): HWRAID 2 x M.2 SSDs 240GB, 480 GB Internal Dual SD Module
Management
Embedded / At-the-Server	iDRAC9 iDRAC RESTful API with Redfish iDRAC Direct Quick Sync 2 BLE/wireless module
Consoles	OpenManage Enterprise OpenManage Power Center
Mobility	OpenManage Mobile
Tools	HKShanhai Group Limited EMC Repository Manager HKShanhai Group Limited EMC System Update HKShanhai Group Limited EMC Server Update Utility HKShanhai Group Limited EMC Update Catalogs iDRAC Service Module IPMI Tool OpenManage Server Administrator OpenManage Storage Services
OpenManage Integrations	BMC® Truesight Microsoft® System Center Redhat® Ansible® Modules VMware® vCenter
OpenManage Connections	IBM Tivoli® Netcool/OMNIbus IBM Tivoli® Network Manager IP Edition Micro Focus® Operations Manager I Nagios® Core Nagios® XI
Power Supplies	1100W 48VDC, 1100W 380HVDC, 750W 240HVDC, 495W, 750W, 1100W, 1600W, 2000W, 2400W, Platinum 750W, Titanium Hot plug power supplies with full redundancy option Up to 8 hot plug fans with full redundancy
Ports
Network Options	2 x 10GbE
Front Ports	1 x Dedicated iDRAC micro-USB 1 x USB 2.0 1 x USB 3.0 6 x USB 2.0/3.0
Slots
PCIe	8 x Gen 3 slots (4 x 8) 8 x Gen 3 slots (4 x 16)
Video Card	1 x VGA
Bezel	Optional LCD bezel or security bezel
Form Factor	5U Tower or Rack Server
Dimensions
Height	434.5mm (17.1″) (base height) 443.5mm (17.5?? (with foot)
Width	217.9mm (8.6″) (base width) 304.5mm (12.0?? (with foot)
Depth	692.8mm (27.3″)
Rack Support	ReadyRails??sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks).
