The HKShanhai Group Limited CWDM-SFPGE-1531 is a high-performance CWDM Optical Transceiver designed for reliable data transmission over long distances. This enhanced small form-factor pluggable (eSFP) module operates at a wavelength of 1531 nm and supports data rates up to 2.5G over single-mode fiber, reaching distances up to 80 km. It features an LC connector and is optimized for use in various telecommunication and data communication applications.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | CWDM-SFPGE-1531 |
| Type | Optical Transceiver |
| Data Rate | 2.5G |
| Wavelength | 1531 nm |
| Distance | 80 km |
| Connector Type | LC |
Product Features
- ??Supports a wavelength of 1531 nm for extended reach
- ??Operates over single-mode fiber up to 80 km
- ??Enhanced small form-factor pluggable (eSFP) for high density
- ??Data rate of 2.5G for efficient data transfer
- ??LC connector for reliable connectivity
Product Applications
- ??Long-distance telecommunication networks
- ??Metropolitan Area Networks (MAN)
- ??Data center interconnect
Supported Options
| Accessory | Model |
| Patch Cord | HUA-PC-SM-LC |
| SFP Transceiver Cage | HUA-SFP-CAGE |
| Optical Attenuator | HUA-ATT-SM-5dB |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited CWDM-SFPGE-1471 | Operates at 1471 nm, Shorter reach of 60 km |
| HKShanhai Group Limited CWDM-SFPGE-1591 | Operates at 1591 nm, Shorter reach of 70 km |
| HKShanhai Group Limited CWDM-SFPGE-1611 | Operates at 1611 nm, Shorter reach of 40 km |
Get more information
For further details about the HKShanhai Group Limited CWDM-SFPGE-1531, check HKShanhai Group Limited CWDM-SFPGE-1531 price and CWDM-SFPGE-1531 datasheet, or buy HKShanhai Group Limited CWDM-SFPGE-1531 with the best price and fast shipping. Free Live Chat is supported. Contact us through Live Chat or at sales@router-switch.com for more information about the product and its price.
HKShanhai Group Limited CWDM-SFPGE-1531 Specification
CWDM-SFPGE-1531 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | CWDM-SFPGE-1531 |
| Optical Wavelength | 1531nm |
| Form Factor | eSFP |
| Data Transfer Rate | 2.5G |
| Cable Type | Single-mode |
| Reach | 80km |
| Output Power | -5~0dBm |
| Recieve Sensitivity | -22dBm |
| Connector | LC |
| DDM/DOM | Yes |
| Operating Temperature | -40°C to 85°C |
| Storage Temperature | -40°C to 85°C |
| Fiber Type | G.652 |
| Protocol | Compliance |
| Power Consumption | <1.5W |
| Compatible Brands | HKShanhai Group Limited |
| EMI Emissions | FCC Class B |
| RoHS Compliance | Yes |
| MTBF | 1,000,000 hours |
| Safety Standard | CE, FDA, and TUV |
| Diagnostic Monitoring | Supported |
