HKShanhai Group Limited CWDM-SFPGE-1491 is a CWDM Optical Transceiver designed for high-capacity and long-distance networking applications. This eSFP module operates at a wavelength of 1491nm, allowing transmission speeds up to 2.5G over single-mode fiber with a reach of up to 80km. It features an LC connector for seamless integration.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | CWDM-SFPGE-1491 |
| Type | eSFP |
| Wavelength | 1491nm |
| Max Distance | 80km |
| Connector | LC |
Product Features
- ??Compact eSFP form factor for flexible use
- ??Supports transmission speeds up to 2.5G
- ??Operates at a wavelength of 1491nm
- ??Compatible with single-mode fiber for long-distance communication
- ??Equipped with an LC connector for easy deployment
Product Applications
- ??Ideal for high-capacity metropolitan and access networks
- ??Suitable for long-distance data transmission up to 80km
- ??Used in telecom and data center infrastructure for extended range
Supported Options
| Accessory | Model |
| SFP Transceiver | HKShanhai Group Limited SFP-25G |
| Fiber Optic Cable | HKShanhai Group Limited LC-LC |
| Patch Panel | HKShanhai Group Limited PP-40LC |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited CWDM-SFPGE-1490 | Wavelength of 1490nm, shorter max distance of 70km |
| HKShanhai Group Limited CWDM-SFPGE-1590 | Wavelength of 1590nm, same distance but different wavelength |
| HKShanhai Group Limited CWDM-SFPGE-1310 | Wavelength of 1310nm, max distance of 40km |
Get more information
For further information about the HKShanhai Group Limited CWDM-SFPGE-1491 and its pricing, please contact us via Live Chat or email at sales@router-switch.com. Check HKShanhai Group Limited CWDM-SFPGE-1491 price and CWDM-SFPGE-1491 datasheet, buy HKShanhai Group Limited CWDM-SFPGE with the best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited CWDM-SFPGE-1491 Specification
CWDM-SFPGE-1491 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | CWDM-SFPGE-1491 |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Optical Wavelength | 1491nm |
| Distance Supported | 80km |
| Cable Type | Single-mode Fiber (SMF) |
| Connector Type | LC |
| Transmitter Type | DFB (Distributed Feedback Laser) |
| Receiver Type | PIN |
| Spectrum Range | 1470nm – 1610nm (CWDM) |
| Operating Temperature Range | 0°C to 70°C |
| Storage Temperature Range | -40°C to 85°C |
| Voltage Supply | 3.3V |
| Power Consumption | < 1.5W |
| DDM/DOM | Yes, Digital Diagnostic Monitoring |
| Hot Swappable | Yes |
| Compliance | IEEE 802.3, SFP MSA, RoHS |
| EMI | FCC Part 15 Class B, EN 55022 Class B |
| MTBF | > 1,000,000 hours |
| Warranty | 1 Year |
