CR2M16BASA13 – NetEngine20E-S Series Universal Service Routers – NE20E-S16A.NE20E-S16A AC Basic Configuration (Includes NE20E-S16A Chassis,2*MPUE1,2*AC Power, Power cord, without Software Charge and Document)
Quick Specs
Figure 1 shows the appearance of HKShanhai Group Limited Router – CR2M16BASA13.
Table 1 shows the Quick Specs.
|
Product Code |
HKShanhai Group Limited Router – CR2M16BASA13 |
|
Switching Capacity |
480 Gbit/s |
|
Forwarding Performance |
360 Mpps |
|
Fixed Ports |
none |
|
Number of Slots |
2 MPUs 2 NSPs 16 PICs |
|
Power module type |
AC power module |
|
Weight |
36.0 kg (AC) |
|
Dimensions (W x D x H) |
353 mm x 442 mm x 220 mm (8U) |
The Optical transceiver
Table 2 shows the recommended elements for the HKShanhai Group Limited Router – CR2M16BASA13.
|
Model |
Description |
|
FE-SFP Optical Transceiver |
|
|
SFP,100M/155M,Multi-mode Module(1310nm,2km,LC) |
|
|
eSFP,100M/155M,Single-mode Module(1310nm,15km,LC) |
|
|
eSFP,FE,Single-mode Module(1310nm,40km,LC) |
|
|
GE-SFP Optical Transceiver |
|
|
SFP,GE,Electrical Interface Module(100m,RJ45) |
|
|
eSFP,GE,Multi-mode Module(850nm,0.55km,LC) |
|
|
eSFP,GE,Single-mode Module(1310nm,10km,LC) |
|
|
eSFP,GE,Single-mode Module(1310nm,40km,LC) |
|
|
eSFP,GE,Single-mode Module(1550nm,40km,LC) |
Compare to Similar Items
Table 3 shows the comparison between CR2M16BASA13 and CR2P2EBASA10.
|
Model |
CR2M16BASA13 |
|
|
Switching Capacity |
480 Gbit/s |
160 Gbit/s |
|
Forwarding Performance |
360 Mpps |
70 Mpps |
|
Fixed Ports |
none |
2 x 10 GE (SFP+) and 24 x GE (SFP) |
|
Number of Slots |
2 MPUs 2 NSPs 16 PICs |
2 PICs |
|
Power module type |
AC power module |
AC power module |
|
Weight |
36.0 kg (AC) |
10.3 kg (AC) |
|
Dimensions (W x D x H) |
353 mm x 442 mm x 220 mm (8U) |
89 mm x 442 mm x 220 mm (2U) |
Get more information
Do you have any question about the CR2M16BASA13
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited CR2M16BASA13 Specification
CR2M16BASA13 Specification |
||
|
Switching Capacity |
480 Gbit/s |
|
|
Forwarding Performance |
360 Mpps |
|
|
Fixed Ports |
— |
|
|
Number of Slots |
|
|
|
Dimensions (H x W x D) |
13.8 in. x 17.4 in. x 8.6 in. = 8U (353 mm x 442 mm x 220 mm = 8U) |
|
|
Power consumption (in full configuration) |
696W (DC) 740W (AC) |
|
|
Weight in Full Configuration |
74.9 lb (34.0 kg) (DC) 79.3 lb (36.0 kg) (AC) |
|
|
Interface Types |
|
|
|
Clock Synchronization |
Synchronous Ethernet and IEEE 1588v2 |
|
|
Layer 2 Features |
|
|
|
IPv4/IPv6 Routing Protocols |
|
|
|
L2/L3 VPN |
|
|
|
Multicast |
|
|
|
QoS |
|
|
|
Reliability |
|
|
|
Security
|
|
|
|
Value-added Services |
NAT, IPSec, GRE, and NetStream |
|
|
OAM |
Y.1731, IP FPM, MPLS OAM, 802.1ag, and 802.3ah |
|
|
Operating Temperature |
32°F to 113°F (0°C to 45°C) |
|
|
Operating Relative Humidity |
5% to 85%, non-condensing |
|
|
Operating Altitude |
??9,842.5 ft. (3,000m) |
