The FiberHome CITRANS 550F E3IF is an advanced STM-16 electrical interface terminal board tailored for seamless integration into telecommunications infrastructures. This robust product supports both 34M and 45M electrical interfaces, ensuring flexible connectivity and enhanced performance for diverse network requirements.
Quick Spec
| Brand | FiberHome |
| Model | CITRANS 550F E3IF |
| Interface | 34M / 45M |
| Technology | STM-16 |
| Type | Electrical Interface Terminal Board |
Product Features
- High compatibility with STM-16 networks
- Supports both 34M and 45M electrical interfaces
- Robust design for sustained performance
- Seamless integration into existing infrastructures
- Enhanced data transmission reliability
Product Applications
- Integration in backbone network infrastructures
- Usage in metropolitan area networks (MANs)
- Deployment in data centers requiring robust connectivity
Supported Options
| Accessory | Model |
| Electrical Cable | XTR-EC-550 |
| Mounting Bracket | MB-550F |
| Connector Adapter | CA-450F |
Compare to Similar Items
| Model | Difference |
| CITRANS 540F EI | Supports only 34M interfaces |
| CITRANS 570F E3IF | Includes additional fiber optic interface |
| CITRANS 510F E2IF | Limited to STM-4 technology |
Get more information
For further details about the FiberHome CITRANS 550F E3IF, including pricing, please contact us through Live Chat or email us at sales@router-switch.com.
FiberHome CITRANS 550F E3IF Specification
FiberHome CITRANS 550F E3IF Specifications |
|
| Brand | FiberHome |
| Product Name | FiberHome CITRANS 550F E3IF |
| Interface | 34M / 45M electrical interface |
| Transmission Technology | STM-16 |
| Board Type | Electrical interface terminal board |
| Connector Type | BNC for E3 and DS3 |
| Speed | 34 Mbps / 45 Mbps |
| Operating Temperature | -5C to 45C |
| Power Supply | AC/DC Input |
| Dimensions | 445mm x 285mm x 65mm |
| Power Consumption | 12W |
| Humidity Range | 10% to 90% (non-condensing) |
| Compliance | ITU-T G.703 |
| MTBF | 120,000 hours |
| Management Interface | Local and remote management |
| Installation | 19-inch rack mountable |
| Indicators | LED indicators for status and alarms |
| Alarm Ports | External alarm ports |
| Cooling | Passive cooling |
