The Cisco 100GBASE-LR4 CFP module supports a link length of 10 kilometers on standard single-mode fiber (SMF, G.652). 100 Gigabit Ethernet signal is carried over four wavelengths. Multiplexing and demultiplexing of the four wavelengths are managed within the device.
Quick Specs
Figure 1 shows the appearance of CFP-100G-LR4.
Table 1 shows the Quick Specs.
|
Product Code |
CFP-100G-LR4 |
|
Part Number |
02310YTD |
|
Description |
High Speed Transceiver,CFP,100G,Single-mode Module(1310nm band,4*25G,10km,stright LC) |
|
Product Series |
USG9500 |
|
Wavelength |
1310nm |
|
Interface |
LC duplex |
|
Cable Type |
SMF |
|
Commercial Temperature Range |
0 to 70°C (32 to 158°F) |
|
Max Data Rate |
103.1 Gbp |
|
Max Cable Distance |
10km |
|
Optical Components |
4x DFB |
|
DOM Support |
Yes |
|
Pack Weight(kg) |
1.5 |
|
Pack Volume(m^3) |
0.026607 |
Compare to Similar Items
Table 2 shows the comparison of CFP-100G-LR4 and CFP2-100G-LR4.
|
Product Code |
CFP-100G-LR4 |
|
|
Part Number |
02310YTD |
02311AEM |
|
Description |
High Speed Transceiver,CFP,100G,Single-mode Module(1310nm band,4*25G,10km,stright LC) |
High Speed Transceiver,CFP2,100G,Single-mode Module(1310nm band,4*25G,10km,stright LC) |
|
Wavelength |
1310nm |
1310nm |
|
Form Type |
CFP |
CFP2 |
|
Max Data Rate |
103.1 Gbp |
112Gbps |
|
Max Cable Distance |
10km |
10km |
|
Optical Components |
4x DFB |
4x DFB |
|
DOM Support |
Yes |
Yes |
Get more information
Do you have any question about theÂ
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited CFP-100G-LR4 Specification
Cisco CFP-100G-LR4 Specification |
|
|
Product Code |
Cisco CFP-100G-LR4 |
|
Average Transmit Power (dBm) |
Max: 4.5 per lane Min: -4.3 per lane |
|
Average Receive Power (dBm) |
Max: 4.5 per lane Min: -10.6 per lane |
|
Transmit and Receive Wavelength |
Four lanes, 1295.6 nm, 1300.1 nm, 1304.6 nm, and 1309.1 nm |
|
Wavelength (nm) |
1310 band (LAN-WDM) |
|
Fiber Type |
SMF |
|
Core Size (microns) |
G.652 |
|
Max Distance* |
10 km |
|
Digital Optical Monitoring (DOM) |
Yes |
