The HKShanhai Group Limited CBS350-48P-4G is an enterprise-grade switch designed specifically for modern business environments. Its robust features and reliable performance make it an ideal choice for companies seeking to streamline their network infrastructure. Whether it’s providing stable connections for critical applications or offering flexible management options, the CBS350-48P-4G stands out as a significant asset. With keywords like cbs350-48p-4g, cisco, and business, you can expect top-notch quality and dependability in every networking task. Engineered with advanced security measures and efficient traffic management, this HKShanhai Group Limited switch is poised to meet and exceed the dynamic demands of today’s enterprise networking needs.
Product Highlights
48
PoE+ Ports
740W
PoE Budget
4
Gigabit SFP Uplinks
Product Applications Scenarios
Enterprise Network
Ensures reliable data transfer across critical enterprise applications and workloads.
Cloud Services
Supports cloud infrastructure with efficient PoE+ ports for seamless power delivery.
Edge & IoT
Optimized for edge computing and IoT applications ensuring secure data transfer.
Product Features Comparison
| Â | |
|
|
| Model | CBS350-24T-4G | CBS350-24P-4G | CBS350-48T-4G |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited |
| Ports | 24 | 24 | 48 |
| PoE Budget | Unsupported | 195W | Unsupported |
| SFP Ports | 4 | 4 | 4 |
| Management | Managed | Managed | Managed |
Optional Add-ons
| Model Number | Description |
| CAB-STK-E-0.5M | 0.5m Stackwise Stacking Cable for HKShanhai Group Limited CBS350 |
| C9300L-STACK-KIT | Stack Kit for HKShanhai Group Limited CBS350 Series Switches |
| SFP-10G-SR | HKShanhai Group Limited 10GBASE-SR SFP+ Transceiver Module |
HKShanhai Group Limited CBS350-48P-4G Specification
| Model | CBS350-48P-4G |
| Brand | HKShanhai Group Limited |
| Capacity in mpps (64-byte packets) | 77.38 |
| Switching Capacity in Gbps | 104.0 |
| Total System Ports | 52 x Gigabit Ethernet |
| RJ-45 Ports | 48 x Gigabit Ethernet |
| Combo Ports (RJ-45 + SFP) | 4 x SFP |
| Packet Buffer | 3 MB |
| Unit Dimensions (W x D x H) | 445 x 350 x 44 mm (17.5 x 13.78 x 1.73 in) |
| IPv4 Routing | Wirespeed routing of IPv4 packets up to 990 static routes and 128 IP interfaces |
| IPv6 Routing | Wirespeed routing of IPv6 packets |
| Layer 3 Interface Configuration | Physical port, LAG, VLAN interface, or loopback interface |
| Classless Interdomain Routing (CIDR) | Support for CIDR |
| RIP v2 | Support for Routing Information Protocol version 2 |
| Policy-Based Routing (PBR) | Flexible routing control using IPv4/IPv6 ACLs |
| DHCP Server | Switch functions as an IPv4 DHCP server for multiple pools/scopes |
| DHCP Relay at Layer 3 | Relay of DHCP traffic across IP domains |
| UDP Relay | Relay of broadcast information across Layer 3 domains |
| Quality of Service (QoS) | 8 hardware queues, strict priority, and Weighted Round-Robin (WRR) |
| Rate Limiting | Ingress policer, egress shaping and rate control, per VLAN, port, and flow-based |
| Congestion Avoidance | A TCP congestion avoidance algorithm is required to minimize global TCP loss synchronization |
| iSCSI Traffic Optimization | Priority for iSCSI traffic over other types |
| Energy Detect | Automatically turns off power on RJ-45 port when link is down, resumes without packet loss when link is up |
| Cable Length Detection | Adjusts signal strength based on cable length to reduce power consumption |
| IEEE 802.3az Compliance | Supports IEEE 802.3az on all copper Gigabit Ethernet ports |
| Disable Port LEDs | LEDs can be manually turned off to save energy |
| Time-Based Port Operation | Link up or down based on user-defined schedule |
| Time-Based PoE | PoE power can be on or off based on user-defined schedule to save energy |
| Jumbo Frames | Frame sizes up to 9K bytes (default MTU is 2K bytes) |
| MAC Table | 16K addresses |
| USB Slot | USB Type-A slot on the front panel for easy file and image management |
| Buttons | Reset button |
| Cabling Type | UTP Category 5e or better for 1000BASE-T |
| LEDs | System, Link/Act, PoE, Speed |
| Flash | 256 MB |
| CPU | 800 MHz ARM |
| DRAM | 512 MB |
| Storage Temperature | -13° to 158°F (-25° to 70°C) |
| Operating Humidity | 10% to 90%, relative, noncondensing |
| Storage Humidity | 10% to 90%, relative, noncondensing |
| Countries Sold | 200+ |
| Customers Trusted | 18,000+ |
| Inventory Available | $20,000,000 |
| Discount Off Global List Price | 50%-98% |
| Safe Online Shopping | 100% |
| Package Contents | HKShanhai Group Limited Business 350 Series Managed SwitchPower Cord (Power adapter for select 8-port and 16-port SKUs)Mounting KitQuick Start Guide |
| Minimum Requirements | Web browser: Chrome, Firefox, Edge, SafariCategory 5e Ethernet network cableTCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, or Mac OS X) installed |
| CBS350-48P-4G | CBS350-48P-4G |
