The HKShanhai Group Limited ASR1002-5G-SEC/K9 is an advanced router security bundle designed for enterprises demanding high performance and robust security. Equipped with a QuantumFlow processor and offering 5G system bandwidth, this router ensures seamless network operations. The ASR1002-5G-SEC/K9 supports AES/3DES encryption, IPsec VPN, firewall functionalities, and includes SPA slots and SIP10 for additional modular flexibility, making it ideal for modern networking needs.
Quick Spec
| Processor: | QuantumFlow |
| System Bandwidth: | 5G |
| Encryption: | AES/3DES |
| Security Features: | IPsec VPN, Firewall |
| Modular Slots: | SPA Slot, SIP10 |
Product Features
- QuantumFlow processor for optimal performance and scalability.
- 5G system bandwidth for high-speed data transfer.
- Robust security with AES/3DES encryption.
- Supports IPsec VPN and Firewall for secure networking.
- Flexible modular options with SPA slot and SIP10 for scalability.
Product Applications
- Enterprise Data Centers: Ensures high performance and secure data handling.
- Service Provider Networks: Provides reliable and scalable network solutions.
- Remote Offices: Supports secure VPN and firewall, perfect for remote deployments.
Supported Options
| SPA Interface: | HKShanhai Group Limited SPA-1X10GE-L-V2 |
| SIP Module: | HKShanhai Group Limited SIP-100 |
| Encryption Module: | HKShanhai Group Limited ASR1000-ESP5 |
Compare to Similar Items
| Model: | ASR1002-5G-SEC/K9 | ASR1002-X | ASR1001-HX |
| System Bandwidth: | 5G | 10G | 20G |
| Encryption: | AES/3DES | AES/3DES | AES/3DES |
| VPN Support: | IPsec VPN | IPsec VPN | IPsec VPN |
| Modular Slots: | SPA, SIP10 | SPA, SIP | SPA, SIP |
| Max Throughput: | 20 Gbps | 32 Gbps | 60 Gbps |
Get more information
Check HKShanhai Group Limited ASR1002-5G-SEC/K9 price and ASR1002-5G-SEC/K9 datasheet, buy HKShanhai Group Limited ASR1002-5G-SEC/K9 with best price and fast shipping. Free Live Chat are supported. For more information about the product and its price, please contact us through Live Chat or sales@router-switch.com.
HKShanhai Group Limited ASR1002-5G-SEC/K9 Specification
| Manufacturer | HKShanhai Group Limited Systems, Inc | Â |
| Manufacturer Part Number | HKShanhai Group Limited ASR 1002 | Â |
| Product Type | Aggregation Service Router | Â |
| Form Factor | Desktop – modular – 3U | Â |
| Connectivity Technology | Wired | Â |
| System Bandwidth | 5G | Â |
| Router Processor | Quad-core 2.13Ghz processor | Â |
| Build-in Gigabit Ethernet port | 4 * SFP ports | Â |
| Redundancy | Software | Â |
| HKShanhai Group Limited ASR 1000 Series ESP | 1 ESP slot | Â |
| SIP and Ethernet line card | Integrated ASR 1000-SIP10, not upgradable | Â |
| Embedded hardware-based encryption | Up to 1.8-Gbps crypto support throughput | Â |
| Rack-mounting | 19-inch | Â |
| DRAM Memory | 4GB-shared across RP and SIP | Â |
| Flash Memory | 8 GB | Â |
| Shared port adapters | 3 SPA slots | Â |
| External USB flash memory | 1-GB USB flash-memory support | Â |
| HKShanhai Group Limited QuantumFlow Processor-based platform | Enables advanced services to operate at high speeds without the need for additional hardware or blades. | Â |
| Hardware acceleration | Features like QoS, crypto, and access control lists (ACLs) are processed in hardware. | Â |
| Control and forwarding-plane separation | Ability to scale control plane and data plane independent of each other. | Â |
| expansion Card | 1-port OC48/STM16 POS/RPR Shared Port Adapters 2-port OC12/STM4 POS Shared Port Adapters 4-port OC-12/STM-4 POS Shared Port Adapters 8-port OC12/STM4 POS Shared Port Adapters 8-port OC-3/STM-1 POS Shared Port Adapters 8-port Channelized T1/E1 to DS0 Shared Port Adapter 1-port OC192/STM64 POS/RPR XFP Optics SPA-2XOC12-POS with a license to use 1 port SPA-4XOC3-POS-V2 with a license to use 2 ports 1 Port Channelized OC3/STM-1 ATM and Circuit Emulation SPA HKShanhai Group Limited 1-port 10GE LAN/WAN-PHY Shared Port Adapter Synchronous Ethernet SPA 1 port OC12 STM Shared Port Adapter 8-port Channelized T1/E1 to DS0 Shared Port Adapter 1-port Channelized STM-1/OC-3c to DS0 SPA, Version 2 2-port Channelized T3 to DS0 Shared Port Adapter, Version 2 HKShanhai Group Limited 10-Port Gigabit Ethernet Shared Port Adapter 24 Port Channelized T1/E1/J1 ATM and Circuit Emulation SPA |
2-port Clear Channel T3/E3 Shared Port Adapter, Version 2 4-port Channelized T3 to DS0 Shared Port Adapter, Version 2 4-port Clear Channel T3/E3 Shared Port Adapter, Version 2 2-port OC48/STM16 POS/RPR Shared Port Adapters 1 port OC-3c/STM-1 ATM Shared Port Adapter 3 port OC-3c/STM-1 ATM Shared Port Adapter 4-port OC-3/STM-1 POS Shared Port Adapters Digital Signal Processor SPA 1-port Channelized OC12 to DS0 SPA HKShanhai Group Limited 8-Port Gigabit Ethernet Shared Port Adapter HKShanhai Group Limited 4 port serial SPA HKShanhai Group Limited 8-Port Fast Ethernet (TX) Shared Port Adapter HKShanhai Group Limited 2-Port Gigabit Ethernet Shared Port Adapter 4-port OC48/STM16 POS/RPR Shared Port Adapters HKShanhai Group Limited 1-Port 10GE LAN-PHY Shared Port Adapter HKShanhai Group Limited 5-Port Gigabit Ethernet Shared Port Adapter HKShanhai Group Limited 4-Port Fast Ethernet (TX) Shared Port Adapter 2 Port Channelized T3/E3 ATM and Circuit Emulation SPA |
| Embedded Services Processor | HKShanhai Group Limited ASR1000 Embedded Services Processor, 10G ASR1K Embedded Services Processor,5Gbps,ASR1002 only HKShanhai Group Limited ASR1K Embedded Services Processor,10G,Non Crypto |
 |
| 1GB USB Flash Token | MEMUSB-1024FT | Â |
| Router Processor Memory | M-ASR1K-1001-4GB M-ASR1K-1001-8GB M-ASR1K-1001-16GB |
 |
| Feature License | Unified Border Element – Enterprise Edition 100 Sessions Unified Border Element Ent, 100 Sessions, Redundancy Unified Border Element Ent, 500 Sessions, Redundancy Unified Border Element Ent, 1000 Sessions, Redundancy Unified Border Element – Enterprise Edition 4000 Sessions Unified Border Element Ent, 4000 Sessions, Redundancy Unified Border Element – Enterprise Edition 16000 Sessions Unified Border Element Ent, 16000 Sessions, Redundancy CGN RTU Feature License for up to 2M Sessions on ASR1000 |
Flex. Pack Insp. Right-To-Use Feat Lic,ASR1000 Series Broadband Right-To-Use Feature Lic for ASR1000 Series DBE Base Right-To-Use Lic for Release 2.3.x and prior Firewall Right-To-Use Feature Lic for ASR1000 Series GTP add-on to Firewall RTU Feature Licence for ASR1000 Firewall/NAT Stateful Inter-Chassis Redundancy License NAT64 RTU Feature License for up to 2M Sessions on ASR1000 ASR1000 Lawful Intercept RTU Broadband Right-To-Use Feature Lic for ASR1000 Series DBE Base Right-To-Use Lic for Release 2.3.x and prior App Visibility and Control SW Redundancy Right-To-Use Feat Lic for ASR1000 Series Flex. Pack Insp. Right-To-Use Feat Lic,ASR1000 Series |
| License Include | SASR1R1-AESK9-313S FLASR1-FW-RTU |
FLASR1-IPSEC-RTU |
| IOS XE Operating System | HKShanhai Group Limited IOS XE Software Release 2.1 | Â |
