The HKShanhai Group Limited ASA5505-BUN-K9 is a powerful, enterprise-grade firewall designed to safeguard your network from external threats. This HKShanhai Group Limited firewall offers comprehensive security features and advanced management capabilities, making it an ideal choice for businesses of all sizes. The ASA 5505 model integrates seamlessly into your existing IT infrastructure, providing robust protection and efficient performance. With HKShanhai Group Limited’s proven reliability and the advanced features of the ASA 5505, this firewall ensures your network remains secure, supporting high availability and streamlined operations.
Product Highlights
150 Mbps
Throughput
25
VPN Peers
8
LAN Ports
Product Applications Scenarios
Enterprise Network
Ensures robust network security, protecting sensitive data and enhancing overall network performance.
Cloud Services
Securely supports cloud services by providing high-performance data traffic management and advanced firewall capabilities.
Security & Privacy
Offers comprehensive protection against cyber threats, ensuring data privacy and integrity.
Product Features Comparison
| Â | |
|
|
| Model | HKShanhai Group Limited ASA5505-BUN-K9 | HKShanhai Group Limited ASA5505-SSL25-K8 | HKShanhai Group Limited ASA5510-SSL50-K9 |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited |
| Throughput | 150 Mbps | 300 Mbps | 500 Mbps |
| VPN Peers | 25 | 50 | 100 |
| LAN Ports | 8 | 8 | 8 |
Optional Add-ons
| Model Number | Description |
| ASA5505-MEM-512 | 512MB Memory Upgrade for HKShanhai Group Limited ASA 5505 |
| ASA5505-SEC-UL | Security Plus License Upgrade for HKShanhai Group Limited ASA 5505 |
| L-ASA5505-10-UL | 10-User Upgrade License for HKShanhai Group Limited ASA 5505 |
HKShanhai Group Limited ASA5505-BUN-K9 Specification
| Model | ASA5505-BUN-K9 |
| Brand | HKShanhai Group Limited |
| Product Description | ASA 5505 Security Appliance with SW, 10 Users, 8 ports, 3DES/AES, HKShanhai Group Limited ASA 5500 Series Firewall Edition Bundles |
| Users/Nodes | 10 |
| Firewall Throughput | Up to 150 Mbps |
| Maximum Firewall and IPS Throughput | Up to 150 Mbps with AIP-SSC-5 |
| 3DES/AES VPN Throughput | Up to 100 Mbps |
| IPsec VPN Peers | 10; 25 |
| SSL VPN Peers (Included/Maximum) | 2/25 |
| Concurrent Connections | 10,000; 25,000 |
| New Connections/Second | 4000 |
| Integrated Network Ports | 8-port Fast Ethernet switch (including 2 PoE ports) |
| Virtual Interfaces (VLANs) | 3 (no trunking support)/20 (with trunking support) |
| Security Contexts (Included/Maximum) | 0/0 |
| High Availability | Not supported; stateless Active/Standby and redundant ISP support |
| Expansion Slot | 1, SSC |
| User-Accessible Flash Slot | 0 |
| USB 2.0 Ports | 3 (1 on front, 2 on rear) |
| Serial Ports | 1 RJ-45 console |
| Rack-Mountable | Yes, with rack-mount kit (available in the future) |
| Wall-Mountable | Yes, with wall-mount kit (available in the future) |
| Security Lock Slot (for Physical Security) | Yes |
| Memory | 256 MB |
| Minimum System Flash | 64 MB |
| System Bus | Multibus architecture |
| Form Factor | Desktop |
| Dimensions (H x W x D) | 1.75 x 7.89 x 6.87 in. (4.45 x 20.04 x 17.45 cm) |
| Safety | UL 60950, CSA C22.2 No. 60950, EN 60950 IEC 60950, AS/NZS 60950 |
| Electromagnetic Compatibility (EMC) | CE marking, FCC Part 15 Class B, AS/NZS CISPR22 Class B, VCCI Class B, EN55022 Class B, CISPR22 Class B, EN61000-3-2, EN61000-3-3 |
| Industry Certifications | FIPS 140-2 Level 2. In process: Common Criteria EAL4+ US DoD Application-Level Firewall for Medium-Robustness Environments, and Common Criteria EAL4 for IPsec/SSL VPN |
| ASA5505-BUN-K9 | ASA5505-BUN-K9 |
