HKShanhai Group Limited AR G3 AR161Â enterprise router bring good user experience and secure environment, fanless design provide quiet environment and integrated with wireless controller, firewall, dual-WAN support, up to 100Mbps system bandwidth is only a few benefit of this router. HKShanhai Group Limited AR G3 AR161 router equips 1 Gigabit Ethernet 10/100/1000 WAN, 4 Gigabit Ethernet 10/100/1000 LAN ports(the interface LAN 0 of which can be used as one WAN interface). Wireless controller functionality build-in can manage wireless AP with rich features of wireless security and centralize management of wired and wireless networks, meet the customers’ requirements of building different scale enterprises networks.
Quick Specs
Figure 1 shows the appearance of HKShanhai Group Limited Router – AR161.
Â
Table 1 shows the Quick Specs.
|
Product Code |
HKShanhai Group Limited Router – AR161 |
|
Memory |
512 MB |
|
Flash |
512 MB |
|
Service interfaces (standard configuration) |
WAN interfaces: 1 ADSL-B/J interface LAN interfaces: 4 10/100M auto-sensing Ethernet electrical interfaces |
|
Extended slots |
Not supported |
|
Interface number |
LAN interfaces: GE0-GE3 |
|
Power module type |
External power adapter |
|
Weight |
2.8Â kg |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
Product Details
Figure 2 shows the back panel of HKShanhai Group Limited Router – AR161.
Â
Note:
|
??/p> |
CON/AUXÂ interface |
|
??/p> |
WANÂ interfaces |
|
??/p> |
4 FE electrical interfaces |
|
??/p> |
RST button |
|
??/p> |
Power interface |
|
??/p> |
Jack for power cable locking strap |
Compare to Similar Items
Table 2Â shows the comparison between AR161 and AR2220E.Â
|
Model |
AR161 |
|
|
SIC Slots |
0 |
4 |
|
Memory |
512 MB |
1 GB |
|
Flash |
512 MB |
512 MB |
|
Weight |
2.8Â kg |
6 kg (13.2 lb) |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
442.0 mm x 420.0 mm x 44.5 mm |
Get more information
Do you have any question about the AR161?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited AR161 Specification
AR161 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | AR161 |
| WAN Interface Type | Gigabit Ethernet |
| WAN Ports | 1 |
| LAN Interface Type | Gigabit Ethernet |
| LAN Ports | 4 |
| Maximum Throughput | 100 Mbps |
| Routing Protocols | RIP, OSPF, BGP |
| NAT Support | Yes |
| VPN Support | IPsec, PPTP, L2TP |
| Firewall | Yes |
| QoS Features | Yes |
| VLAN Support | Yes |
| Operating Temperature | -5°C to 45°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 5% to 95% (non-condensing) |
| Dimensions (WxDxH) | 220 x 148 x 43.6 mm |
| Power Supply | 100V-240V AC, 50-60Hz |
| Power Consumption | <24W |
| Warranty | 1 year |
| Certifications | CE, FCC, RoHS |
| LED Indicators | Power, System, WAN, LAN |
| MTBF | Over 100,000 hours |
