GPON ONTs series equipments are manufactured and developed by FiberHome for home and SOHO users used in FTTH solution. They are properly managed with features such as high-bandwidth, high-reliability, low power consumption and satisfy the user’s triple-play requirements. AN5506-04-FAT is a FiberHome ONT with Wi-Fi.
Quick Spec
Table 1 shows the quick spec.
|
Type |
AN5506-04-FAT |
|
Dimension H/W/D(mm) |
37*252*178 |
|
NNI |
GPON |
|
UNI |
4*GE+2*POTS+WiFi |
|
WiFi |
2.4GHz(11n3*3) 5GHz(11ac3*3) |
Product Details
FiberHome GPON ONTs provide these key features:
– Suitable for home broadband, e-governmerit and enterprise access with integrated access demands of broadband/voice/data/video etc.
– Providing complete series of FTTH solutions for pure data, double play and triple play services, both indoor and outdoor types can be applied to meet the different application environment.
– Smart connection by multiple kinds of UN Is: GE/FE, POTS, Wi-Fi, CATV.
– User-friendly GUI with plug-in and play capability instead of field configuration High efficiency management and maintenance with port-based mode configuration as well as port-based status query.
– Telecom-level reliability in hardware/software and other system design to fully guarantee the normal operation of equipment.
Typical Application Scenarios
  Â
Compare to Similar Items
Table 2 shows the comparison.
|
Type |
AN5506-04-FAT |
||||||
|
Dimension H/W/D(mm) |
32*156*115 |
36.8*204*149 |
36.8*204*149 |
36.8*204*149 |
36.8*204*149 |
37*252*178 |
37*252*178 |
|
NNI |
GPON |
GPON |
GPON |
GPON |
GPON |
GPON |
GPON |
|
UNI |
2*GE+2*FE+l*POTS+WiFi |
4*GE+2*POTS+WiFi |
4*GE+2*POTS+WiFi |
4*GE+1*POTS+WiFi |
4*GE+2*POTS+WiFi |
4*GE+2*POTS+WiFi |
4GE+2*POTS+WiFi |
|
WiFi |
2.4GHz (11n2*2) |
2.4GHz (11n2*2) |
2.4GHz(11n2*2) 5GHz(11ac2*2) |
2.4GHz(11n2*2) 5GHz(11ac2*2) |
2.4GHz(11n2*2) 5GHz(11ac3*3) |
2.4GHz(11n3*3) 5GHz(11ac3*3) |
2.4GHz(11ax3*3) 5GHz(11ax3*3) |
|
Power Supply |
AC:220V DC:12V/1A |
AC:220V DC:12V/1.5A |
AC:220V DC:12V/1.5A |
AC:220V DC:12V/1.5A |
AC:220V DC:12V/2A |
AC:220V DC:12V/2.5A |
AC:220V DC:12V/2.5A |
|
Power Consumption |
??0W |
??2W |
??7W |
??7W |
??8W |
??8W |
W24W |
|
Operating Temperature |
5°C-45°C |
-5°C~45°C |
-5°C~45°C |
-5°C~45°C |
5°C~45°C |
-5°C~45°C |
5°C~45°C |
Get More Information
Do you have any question about the AN5506-04-FAT
Contact us now via Live Chat or sales@router-switch.com.
FiberHome AN5506-04-FAT Specification
AN5506-04-FATÂ Specification |
|
|
Dimension H/W/D(mm) |
37*252*178 |
|
NNI |
GPON |
|
UNI |
4*GE+2*POTS+WiFi |
|
WiFi |
2.4GHz(11n3*3) 5GHz(11ac3*3) |
|
Power Supply |
AC:220V DC:12V/2.5A |
|
Power Consumption |
??8W |
|
Operating Temperature |
-5°C~45°C |
