The HKShanhai Group Limited AIR-ANT25137NP-R4 is an advanced 2.4 GHz 13 dBi/5 GHz 7 dBi 11n Dual Band Patch Antenna, offered in a convenient pack of four. Ideal for a variety of wireless communication needs, this dual-band patch antenna provides exceptional performance and reliability. With HKShanhai Group Limited’s trusted engineering, the AIR-ANT25137NP-R4 meets diverse connectivity challenges with ease.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | AIR-ANT25137NP-R4 |
| Frequency Band | 2.4 GHz / 5 GHz |
| Gain | 2.4 GHz: 13 dBi / 5 GHz: 7 dBi |
| Quantity | 4 |
Product Features
- High-gain antenna capable of dual-band frequency (2.4 GHz and 5 GHz).
- Enhanced signal strength with 13 dBi for 2.4 GHz and 7 dBi for 5 GHz for optimal coverage.
- Includes four antennas for comprehensive deployment.
- Compatible with 802.11n wireless networks.
- Designed for easy installation and robust performance.
Product Applications
- Expanding wireless coverage in large open spaces such as warehouses and production floors.
- Improving signal reliability in office buildings with multiple floors and numerous obstacles.
- Providing stable and strong connections in outdoor environments like parks or campus areas.
Supported Options
| Accessory | Model |
| Mounting Bracket | AIR-ACC3355 |
| Coaxial Cable | AIR-CAB005LL-N |
| Lightning Arrestor | AIR-PWR-ADPT |
Compare to Similar Items
| Model | Differences |
| AIR-ANT2524DB-R | Lower gain of 2.4 GHz: 2 dBi, 5 GHz: 4 dBi |
| AIR-ANT2547VG-N | Vertically polarized design, 2.4 GHz: 4 dBi, 5 GHz: 7 dBi |
| AIR-ANT2588P3M-N | Higher 5 GHz gain at 8 dBi |
Get more information
For further information about the HKShanhai Group Limited AIR-ANT25137NP-R4, including pricing and availability, contact us via Live Chat or at sales@router-switch.com. Check HKShanhai Group Limited AIR-ANT25137NP-R4 price and AIR-ANT25137NP-R4 datasheet, buy HKShanhai Group Limited AIR-ANT25137NP-R4 with the best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited AIR-ANT25137NP-R4 Specification
AIR-ANT25137NP-R4 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | AIR-ANT25137NP-R4 |
| Frequency Range | 2.4 GHz / 5 GHz |
| Gain | 13 dBi (2.4 GHz) / 7 dBi (5 GHz) |
| Technology | 802.11n |
| Antenna Type | Dual Band Patch |
| Quantity | 4 |
| Polarization | Linear |
| Connector Type | N-female |
| Impedance | 50 Ohms |
| Antenna Dimensions | 10.4 x 9.4 x 2.8 inches |
| Operating Temperature | -40C to 85C |
| Storage Temperature | -40C to 85C |
| Mounting | Wall/Pole Mount |
| VSWR | 2:1 or Less |
| Maximum Input Power | 20 Watts |
| Beamwidth (H-plane) | 50 |
| Beamwidth (E-plane) | 50 |
| Waterproof Level | IP67 |
| Wind Rating | 125 mph (201 km/h) |
| Lightning Protection | DC Grounded |
