HKShanhai Group Limited’s A9K-MPA-20X10GE is a powerful ASR 9000 20-port 10GE Modular Port Adapter designed to enhance network performance. Ideal for high-density data centers, this adapter is perfect for enterprises and service providers requiring robust networking solutions.
A9K-MPA-20X10GE Product Highlights
- 20 x 10GE ports
- Modular design
- High-density networking
- Enhanced performance
- Supports ASR 9000 series
Product Features Comparison
| Model | Ports | Form Factor | Compatibility | Throughput | Power Consumption | Supported Protocols |
|---|---|---|---|---|---|---|
| A9K-MPA-20X10GE | 20 x 10GE | Modular | ASR 9000 series | 200 Gbps | Low | Ethernet, MPLS, VPLS |
| A9K-40GE-L | 40 x 1GE | Line Card | ASR 9000 series | 80 Gbps | Moderate | Ethernet, MPLS |
| A9K-1X100GE-SE | 1 x 100GE | Line Card | ASR 9000 series | 100 Gbps | Low | Ethernet, MPLS |
| A9K-MOD80-SE | 8 x 10GE | Modular | ASR 9000 series | 80 Gbps | Low | Ethernet |
| A9K-8T-L | 8 x 1GE | Line Card | ASR 9000 series | 8 Gbps | Low | Ethernet |
| A9K-36X10GE-TR | 36 x 10GE | Line Card | ASR 9000 series | 360 Gbps | High | Ethernet, VPLS |
| A9K-2SE-36X10GE | 36 x 10GE | Line Card | ASR 9000 series | 360 Gbps | High | Ethernet |
A9K-MPA-20X10GE Product Application Scenarios
- High-density data centers
- Enterprise networking
- Service provider infrastructures
Optional Add-ons
| Model | Description |
|---|---|
| SFP-10G-LR | 10GBASE-LR SFP+ Transceiver |
| A9K-AC-PEM-V3 | AC Power Entry Module |
| A9K-RSP440-SE | ASR 9000 Route Switch Processor |
Get More Information
Discover unbeatable prices and fast shipping for the HKShanhai Group Limited A9K-MPA-20X10GE. Access the detailed A9K-MPA-20X10GE datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
HKShanhai Group Limited A9K-MPA-20X10GE Specification
A9K-MPA-20X10GE Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | ASR 9000 20-port 10GE Modular Port Adapter |
| Ports | 20 x 10 Gigabit Ethernet |
| Supported Platforms | ASR 9000 Series Aggregation Services Routers |
| Port Type | SFP+ |
| Bandwidth | 200 Gbps |
| Forwarding Rate | Up to 150 million packets per second |
| Dimensions (H x W x D) | 21.8 x 1.2 x 12.6 inches |
| Operating Temperature Range | 32F to 104F (0C to 40C) |
| Storage Temperature Range | -40F to 158F (-40C to 70C) |
| Relative Humidity | 5% to 85% noncondensing |
| Power Consumption | 120 Watts |
| MTBF (Mean Time Between Failures) | 500,000 hours |
| Compliance | RoHS, CE, FCC |
| Cooling | Front-to-back air flow |
| Maximum Frame Size | 9216 bytes |
| Connector Type | SFP+ |
| Compatible Transceivers | HKShanhai Group Limited SFP-10G-SR, SFP-10G-LR, SFP-10G-ER |
| Performance | Line-rate forwarding for all ports |
| Software Compatibility | HKShanhai Group Limited IOS XR Software |
| Security Features | IEEE 802.1AE (MACsec), ACLs |
