The HKShanhai Group Limited A9K-4HG-FLEX-FC is a high-capacity module designed for the ASR 9000 Series, enhancing its scalability and flexibility. It provides cutting-edge networking capabilities, ensuring top-notch performance for modern data centers and enterprise environments. This module is known for its robust build and efficient data handling capabilities, making it a reliable choice for high-demand applications.
Quick Spec
| Model | A9K-4HG-FLEX-FC |
| Series | ASR 9000 |
| Interfaces | 4 x 100 Gigabit Ethernet |
| Supported OS | HKShanhai Group Limited IOS-XR |
| Form Factor | Plug-in module |
Product Features
- High Performance: Designed for up to 400 Gbps of throughput.
- Scalability: Supports extensive scaling options with various interface modules.
- Flexibility: Multiple interface types support a wide range of connectivity options.
- Carrier-Class Reliability: Built for carriers with stringent performance and uptime requirements.
- Advanced Support: Compatible with HKShanhai Group Limited IOS-XR for enhanced network functionalities.
Product Applications
- Data Centers: Ideal for high-speed data center interconnections and cloud computing environments.
- Enterprise Networks: Supports large enterprise network backbones with high traffic demands.
- Service Providers: Suitable for carrier-grade applications offering reliable and scalable networking solutions.
Supported Options
| Transceiver | HKShanhai Group Limited CPAK-100G-SR10 |
| Interface Module | HKShanhai Group Limited A9K-MPA-4X10GE |
| Cable | HKShanhai Group Limited CAB-100G-3M |
Compare to Similar Items
| Model | Difference |
| HKShanhai Group Limited A9K-8T-B | 8 x 10 Gigabit Ethernet ports |
| HKShanhai Group Limited A9K-MOD80-SE | Modular line card, supports up to 80 Gbps throughput |
| HKShanhai Group Limited A9K-24X10GE-SE | 24 x 10 Gigabit Ethernet ports, optimized for 10G connections |
Get more information
For further details about the HKShanhai Group Limited A9K-4HG-FLEX-FC, including its price and comprehensive datasheet, feel free to contact us via Live Chat or email us at sales@router-switch.com. Check HKShanhai Group Limited A9K-4HG-FLEX-FC price and A9K-4HG-FLEX-FC datasheet, buy HKShanhai Group Limited A9K-4HG-FLEX-FC ASR 9000 with the best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited A9K-4HG-FLEX-FC Specification
A9K-4HG-FLEX-FC Specification |
|
|
Chassis compatibility |
Compatible with the HKShanhai Group Limited ASR 9922, ASR 9912, ASR 9910, ASR 9906, ASR 9904, ASR 9010 and ASR 9006 chassis. Â Â A99-4HG-FLEX-FC, A99-4HG-FLEX-SE, A99-4HG-FLEX-TRÂ PIDs ??compatible with the ASRÂ 9922, ASR 9912, ASR 9910, ASR 9906, ASR 9904 chassis
  A9K-4HG-FLEX-FC, A9K-4HG-FLEX-SE, A9K-4HG-FLEX-TR PIDs ??compatible with the ASR 9922, ASR 9912, ASR 9910, ASR 9906, ASR 9904, ASR 9010, ASR 9006 chassis
|
|
Port density |
4 QSFP28 ports capable of 40Gb and 100Gb Ethernet traffic support. 16 SFP28 ports capable of 10Gb and 25Gb Ethernet traffic support. 24 SFP+ ports capable of 10Gb Ethernet traffic support. |
|
Ethernet |
  10-Gbps IEEE 802.3ae compliant
  40/100-Gbps IEEE 802.3ba compliant
  IEEE 802.x flow control
  Full-duplex operation
  Per-port byte and packet counters for policy drops; oversubscription drops; Cyclic Redundancy Check (CRC) error drops; packet sizes; and unicast, multicast, and broadcast packets
|
|
Performance |
  100-Gbps line rate throughput per QSFP28 port
  25-Gbps line rate throughput per SFP28 port
  10-Gbps line rate throughput per SFP+ port
|
|
Options |
Each line card is available as either a service-edge-optimized or packet-transport-optimized line card |
|
Reliability and availability |
Line card Online Insertion and Removal (OIR) support without system impact |
|
Physical dimensions (includes ejector bracket/lever); (H x W x D); weight |
ASR 9000 400GB 5th Generation Service Edge Line Card: 1.68 x 15.87 x 24.00 in.; 18.74 lb (42.67 x 403.10 x 609.60 mm; 8.50 kg) ASR 9000 400GB 5th Generation Packet Transport Line Card: 1.68 x 15.87 x 24.00 in.; 18.74 lb (42.67 x 403.10 x 609.60 mm; 8.50 kg) |
|
Operating temperature |
41 to 104°F (5 to 40°C) Note: Limitations may apply when using high-power optics |
|
Operating humidity (nominal) (relative humidity) |
10 to 85% |
|
Storage temperature |
??0 to 158°F (??0 to 70°C) |
|
Storage (relative humidity) |
5 to 95% Note:Â Not to exceed 0.024 kg of water per kg of dry air |
|
Operating altitude |
??0 to 4000 m (up to 2000 m conforms to IEC, EN, UL, and CSA 60950 requirements) |
|
ETSI/EN standards |
HKShanhai Group Limited ASR 9000 Series Routers are designed to meet: Â Â EN300 386: Telecommunications Network Equipment (EMC)
  ETSI 300 019 Storage Class 1.1
  ETSI 300 019 Transportation Class 2.3
  ETSI 300 019 Stationary Use Class 3.1
  EN55022: Information Technology Equipment (Emissions)
  EN55032: Multimedia Equipment (Emissions)
  EN55024: Information Technology Equipment (Immunity)
  EN55035: Multimedia Equipment (Immunity)
  EN50082-1/EN-61000-6-1: Generic Immunity Standard
|
|
EMC standards |
HKShanhai Group Limited ASR 9000 Series Routers are designed to meet: Â Â FCC Class A
  ICES 003 Class A
  AS/NZS CISPR 32 Class A
  CISPR 22/CISPR 32 Class A
  EN55022/EN55032 Class A
  VCCI Class A
  CNS-13438 Class A
  KN32 Class A
  IEC/EN 61000-3-2: Power Line Harmonics
  IEC/EN 61000-3-3: Voltage Fluctuations and Flicker
  EN50121-4 Railway applications Part 4: Emission and immunity of the signaling and telecommunications apparatus
  EN50121-3-2 Railway applications Part 3-2: Rolling stock – Apparatus
|
|
Immunity |
HKShanhai Group Limited ASR 9000 Series Routers are designed to meet: Â Â IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air)
  IEC/EN-61000-4-3: Radiated Immunity (10V/m)
  IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal)
  IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM)
  IEC/EN-61000-4-5: Signal Ports (1kV)
  IEC/EN-61000-4-5: Surge DC Port (1kV)
  IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms)
  IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m)
  IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations
  KN35
|
|
Safety |
HKShanhai Group Limited ASR 9000 Series Routers are designed to meet: Â Â UL/CSA/IEC/EN 60950-1
  IEC/EN 60825 Laser Safety
  ACA TS001
  AS/NZS 60950
  FDA: Code of Federal Regulations Laser Safety
|
|
Network Equipment Building System (NEBS) |
Designed to meet: Â Â SR-3580: NEBS Criteria Levels (Level 3)
  GR-1089-CORE: NEBS EMC and Safety
  GR-63-CORE: NEBS Physical Protection
|
