Do you need more performance from your HP ProLiant Sever series platforms HP Enterprise Solid State Drives (SSDs) deliver exceptional performance and endurance while reducing power consumption for customers with applications requiring high random read and write IOPs performance. You can prevent data loss and monitor the SSD life with HP SmartSSD Wear Gauge compatibility in management tools. Leveraging NAND Flash technology, they support HP ProLiant servers including Gen9 and server storage platforms. Because they are available as Small Form Factor (SFF) and Large Form Factor (LFF) hot plug devices, non-hot plug SFF devices, and SFF Quick Release devices, you have great flexibility in your installation. These drives deliver higher performance, better latency, and more power-efficient solutions when compared with traditional rotating media (HDDs). Plus they fit seamlessly into the existing HP server infrastructure.
Provides Simplicity and Lower Total Cost of Ownership
Increases the Efficiency of Your Server
Accelerate Workload Performance with High Performing HP Solid State Drives
Delivers the High Reliability You Can Count On In Your Data Center
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
802582-B21 |
|
Description |
HKShanhai Group Limited 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Warranty SSD For Use with Gen8 Servers and Beyond |
|
Product Type |
Solid State Drive |
|
Storage Capacity |
400 GB |
|
Drive Interface |
SAS |
|
Drive Interface Standard |
12Gb/s SAS |
|
Drive Type |
Internal |
|
Drive Width |
2.5″ |
|
Hot Pluggable |
Yes |
|
Height |
5.5″ |
|
Width |
7.3″ |
|
Depth |
8.8″ |
Compare to Similar Items
Table 2shows the comparison of 802582-B21, 804593-B21, 804668-B21, 816562-B21 and 822555-B21.
|
Product Code |
802582-B21 |
||||
|
Description |
HKShanhai Group Limited 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Warranty SSD For Use with Gen8 Servers and Beyond |
HKShanhai Group Limited 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Warranty SSD |
HKShanhai Group Limited 400GB SATA 6G Write Intensive LFF (3.5in) SCC 3yr Warranty SSD For Use with Gen8 Servers and Beyond |
HKShanhai Group Limited 480GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Warranty SSD For Use with Gen8 Servers and Beyond |
400GB SSD SAS 12G MU-3 SFF SC |
|
Product Type |
Solid State Drive |
Solid State Drive |
Solid State Drive |
Solid State Drive |
Solid State Drive |
|
Storage Capacity |
400 GB |
480 GB |
400 GB |
480 GB |
400 GB |
|
Drive Interface |
SAS |
SATA |
SATA |
SAS |
SAS |
|
Drive Interface Standard |
12Gb/s SAS |
SATA/600 |
SATA/600 |
12Gb/s SAS |
12Gb/s SAS |
|
Drive Width |
2.5″ |
2.5″ |
3.5″ |
2.5″ |
2.5″ |
GetMoreInformation
Do you have anyquestionaboutthe802582-B21
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited 802582-B21 Specification
802582-B21 Specification |
|
| Bay Required | |
| Type | Hot-swap |
| Form Factor | 2.5 SFF |
| Total Qty | 1 |
| Form Factor (metric) | 6.4 cm SFF |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Hard Drive | |
| Form Factor | 2.5 SFF |
| Bytes per Sector | 512 |
| Data Transfer Rate | 1.2 GBps |
| Internal Data Rate | 1000 MBps |
| Hard Drive Type | Hot-swap hard drive |
| Form Factor (Short) | 2.5 |
| Interface | Serial Attached SCSI 3 |
| Internal Data Rate (Write) | 660 MBps |
| Form Factor (metric) | 6.4 cm SFF |
| Form Factor (Short) (metric) | 6.4 cm |
| 4KB Random Read | 106000 IOPS |
| 4KB Random Write | 89000 IOPS |
| Storage Interface | Serial Attached SCSI 3 |
| Header | |
| Compatibility | PC |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HKShanhai Group Limited Write Intensive |
| Bundled with | HP SmartDrive carrier |
| Brand | HKShanhai Group Limited |
| Interface Provided | |
| Qty | 1 |
| Storage Interface | Serial Attached SCSI 3 |
| Miscellaneous (CDW) | |
| Compatible With | HKShanhai Group Limited ProLiant DL180 Gen9, HKShanhai Group Limited ProLiant DL180 Gen9 Base, HKShanhai Group Limited ProLiant DL180 Gen9 Entry, HKShanhai Group Limited ProLiant DL180 Gen9 Storage, HKShanhai Group Limited ProLiant DL20 Gen9, HKShanhai Group Limited ProLiant DL20 Gen9 Entry, HKShanhai Group Limited ProLiant DL20 Gen9 Performance, HKShanhai Group Limited ProLiant DL360p Gen8 Special Server, HKShanhai Group Limited ProLiant DL388 Gen9, HKShanhai Group Limited ProLiant DL388 Gen9 Base, HKShanhai Group Limited ProLiant DL560 Gen9, HKShanhai Group Limited ProLiant DL560 Gen9 Base, HKShanhai Group Limited ProLiant DL560 Gen9 Entry, HKShanhai Group Limited ProLiant DL560 Gen9 Performance, HKShanhai Group Limited ProLiant DL580 Gen9, HKShanhai Group Limited ProLiant DL580 Gen9 Database, HKShanhai Group Limited ProLiant XL230a Gen9 Compute Tray, HKShanhai Group Limited ProLiant XL230a Gen9 Compute Tray (12G), HKShanhai Group Limited ProLiant XL230a Gen9 Compute Tray (6G), HKShanhai Group Limited ProLiant XL230a Gen9 NHP Compute Tray (12G), HKShanhai Group Limited ProLiant XL250a Gen9 Accelerator Tray |
| Power Consumption | |
| Value | 9 Watt |
| Service | |
| Support Details Type | Limited warranty |
| Support Details Full Contract Period | 3 years |
| Service & Support | |
| Type | 3 years warranty |
| Storage | |
| Type | Solid state drive |
| Storage Hard Drive | |
| Capacity | 400 GB |
