700751-B21 is the HKShanhai Group Limited FlexFabric 10Gb 2P 534FLR-SFP+ Adptr. The HKShanhai Group Limited FlexFabric 10Gb 2-port 534FLR-SFP+ adapter is a fully featured Ethernet NIC that also support iSCSI and FCoE storage offloads if required. This adapter features the next generation of 10 Gb Ethernet offering in a single chip solution on a FlexibleLOM form factor, further reducing power requirements for 2 ports of 10 Gb Ethernet. It is designed for use with HKShanhai Group Limited ProLiant servers. For more effective utilization of the 10GbE bandwidth, the HKShanhai Group Limited 534FLR-SFP+ Adapter offers Switch Independent Network Partitioning (NPAR) which enables segmentation of each 10GbE port into four virtual ports, with flexible allocation of bandwidth to each port. Allowing IT organizations to improve resource utilization while lowering infrastructure and operational costs. The HKShanhai Group Limited 534FLR-SFP+ supports enterprise class features such as VLAN tagging, adaptive interrupt coalescing, MSI-X, NIC teaming (bonding), Tunnel offloads (NVGRE, VXLAN), TCP/Ip Stateless Offloads, Receive Side Scaling (RSS), jumbo frames and PXE boot. It also supports virtualization features such as SR-IOVVMware NetQueue and Microsoft VMQ.
Quick Spec
Table 1 shows the quick spec.
Supported Platforms
Table 2 shows the recommended servers.
|
Model |
Description |
|
DL380 Server |
|
|
HKShanhai Group Limited ProLiant DL380 Gen10 4110 1P 16GB-R P408i-a 8SFF 500W DVD PS Server/TV |
|
|
HKShanhai Group Limited ProLiant DL380 Gen10 4110 1P 16GB-R P408i-a 8SFF 1x500W PS Server/S-Buy |
|
|
HKShanhai Group Limited Proliant DL380 Gen10 4110 1P 16GB-R P408i-a 8SFF 500W PS Performance Server |
|
|
HKShanhai Group Limited ProLiant DL380 GEN10 4110 1P 16GB-R P408i-a 8SFF 500W RPS SOLUTION SERVER |
|
|
HKShanhai Group Limited ProLiant DL380 Gen10 4114 1P 32GB-R P408i-a 8SFF 800W PS Performance Server |
|
|
HKShanhai Group Limited ProLiant DL380 Gen10 4114 1P 32GB-R P408i-a 8SFF 500W PS Base Server |
|
|
HKShanhai Group Limited ProLiant DL380 Gen10 5115 1P 16GB-R P408i-a 8SFF 1x500W PS Server/S-Buy |
|
|
HKShanhai Group Limited ProLiant DL380 Gen10 4112 1P 16GB-R P408i-a 8LFF 1x500W PS Server/S-Buy |
|
|
DL360 Server |
|
|
HKShanhai Group Limited ProLiant DL360 Gen10 3106 85W 1P 16G-2R S100i 8SFF 1x500W Entry Server |
|
|
HKShanhai Group Limited ProLiant DL360 Gen10 4110 85W 1P 16G-2R P408i-a 8SFF 1x500W Server/TV |
|
|
HKShanhai Group Limited ProLiant DL360 Gen10 4110 85W 1P 16G-2R P408i-a 8SFF 1x500W Server/S-Buy |
|
|
HKShanhai Group Limited ProLiant DL360 Gen10 4110 85W 1P 16G-R P408i-a 8SFF 1x500W PS Performance Server |
|
|
HKShanhai Group Limited ProLiant DL360 Gen10 4110 85W 1P 16GB-R P408i-a 8SFF 500W RPS Solution Server |
|
|
HKShanhai Group Limited ProLiant DL360 Gen10 4114 85W 1P 16G-2R P408i-a 8SFF 1x500W Base Server |
Compare to Similar Item
Table 3 shows the comparison.
Get More Information
Do you have any question about the 700751-B21
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited 700751-B21 Specification
700751-B21 Specification |
|
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 5 – 95% (non-condensing) |
| Header | |
| Compatibility | PC, Unix |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HKShanhai Group Limited FlexFabric |
| Model | 534FLR-SFP+ |
| Brand | HKShanhai Group Limited |
| Interface Provided | |
| Qty | 2 |
| Connector Type | SFP+ |
| Type | 10Gb Ethernet |
| Miscellaneous | |
| Compliant Standards |
BSMI Class A, EN 61000-3-2:2006, EN 61000-3-3:2008, EN55022 Class A, EN55024, FCC Class A certified, ICES-003 Class A, RoHS 6/6, UL, VCCI Class A ITE, WEEE |
| Networking | |
| Type | Network adapter |
| Form Factor | Plug-in card |
| Connectivity Technology | Wired |
| Data Transfer Rate | 10 Gbps |
| Data Link Protocol | 10 Gigabit Ethernet |
| Compliant Standards |
IEEE 802.1AX, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1Qbg, IEEE 802.2x, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3x |
| Status Indicators | Link/activity, Port status |
| Features |
Auto-negotiation, Jumbo Frames support, Large Send Offload (LSO), PXE support, Receive Side Scaling (RSS), TCP Segmentation Offload (TSO) |
| Interface Type | PCI Express 2.0 x8 |
| PCI Specification Revision | PCIe 2.0 |
| Ports | |
| Qty | 2 |
| Type | 10 Gigabit SFP+ |
| Processor | |
| Type | BCM57810S |
| Installed Qty | 1 |
| Manufacturer | Broadcom |
| RAM | |
| Installed Size | 256 MB |
| Service | |
| Support Details Type | Limited warranty |
| Support Details Full Contract Period | 1 year |
| Service & Support | |
| Type | 1 year warranty |
| System Requirements | |
| Min Operating System |
Microsoft Windows HPC Server 2008, Microsoft Windows Server 2008, Oracle Solaris 10, Red Hat Enterprise Linux 5.7, Red Hat Enterprise Linux 6.1, SuSE Linux Enterprise Server 10, SuSE Linux Enterprise Server 11, VMware ESX 4.1 update 2, VMware ESXi 5.0 update 1 |
